Product Details
Place of Origin: CHINA
Brand Name: ACC
Certification: CE ISO
Model Number: ACC-65
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: USD+40000+SET
Packaging Details: film and wood box package
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 1+45+WORK DAYS
|
Suitable Materiao:
|
PE PP PVC TPU
|
Machineweight:
|
3000 - 5000 Kg
|
Motor Brand:
|
Simens Beide
|
Power:
|
30-200kw
|
Pvc Sheet Width:
|
500-5000mm
|
Length:
|
3m To 20m
|
Electric Control:
|
PLC
|
Speed:
|
10-200 M/min
|
Screw Design:
|
Single Screw & Double Screw
|
Film Thickness:
|
0.2-3mm
|
Raw Material:
|
TPU,EVA,PP,PE
|
Warranty Time:
|
One Year
|
|
Suitable Materiao:
|
PE PP PVC TPU
|
|
Machineweight:
|
3000 - 5000 Kg
|
|
Motor Brand:
|
Simens Beide
|
|
Power:
|
30-200kw
|
|
Pvc Sheet Width:
|
500-5000mm
|
|
Length:
|
3m To 20m
|
|
Electric Control:
|
PLC
|
|
Speed:
|
10-200 M/min
|
|
Screw Design:
|
Single Screw & Double Screw
|
|
Film Thickness:
|
0.2-3mm
|
|
Raw Material:
|
TPU,EVA,PP,PE
|
|
Warranty Time:
|
One Year
|
I. MAIN PARAMETERS:
1. Processed Material: PP/PS/PE Granule or powder
2. Max. width of finished product after slitted: 680mm
3. Thickness of the finished product: 0.3-2.0mm
4. Max. output capacity of extruder: around 180-250Kg/h
5. Machine Frame: square steel
II. Configuration and Specification
1. Direct connection way between motor and gear box
2. Main motor: 55KW
3. Main screw: 110mm, L/D: 33:1
4. Aluminum heater
5. Non-stop Fast Screen Changer With Double-sieve
6. The effective width of the die head: 800mm
7. Calender Roll Stack
(1) Structure: the three-rollers calender lay on the round with 45° slantways,
(2) Roll number: 3
(3) Diameter of roll: 350mm
(4) Roll length: 780mm
8. Single-shaft Winder 1 set
9. Waste sheet reweinder 1 set
10. Thermostat 2 sets (only for making PS sheet)
11. Electronic Control Cabinet (one set)
Main Technical Parameters:
| Model | FJL-PC-90-A/B | FJL-PC-100-A/B | FJL-PC-105-A/B | FJL-PC-110-A/B | FJL-PC-115-A/B | FJL-PC-120-A/B |
| Raw Material | PP,HIPS,PE | |||||
| Sheet Thickness | 0.3-2mm | |||||
| Layer | 1 | |||||
| Capacity | 100kg/h | 150kg/h | 175kg/h | 200kg/h | 225kg/h | 250kg/h |
| Screw Dia. | 90mm | 100mm | 105mm | 110mm | 115mm | 120mm |
| L/D Ratio | 32:1 | |||||
| Roller Dia. | 300mm | 320mm | 350mm | 350mm | 400mm | 450mm |
| Main Motor Power | 37kw | 45kw | 45kw | 55kw | 75kw | 90kw |
| Overall Power | 90kw | 100kw | 110kw | 120kw | 135kw | 160kw |
| Weight | 5.5T | 6T | 6.5T | 7T | 7.5T | 8T |
| Power Supply | 380V/50HZ/3P |
|||||
